V Shape Wire Wrapped Continuous Slot Screen For Water Treatment System
Rod Based Wire Wrapped Screen consist of V-shape profile wire and the longitudinal support rods. the V-wire is welded to the rods and produces a rigid unit that has high strength and minimum weight. So wedge wire screen has sturdy constriction and good mechanical property.
Wire Wrapped Screen Advantage
wedge wire Screen for Self Cleaning Strainer
High mechanical load capacity
No form closure connection that would allow vibration of the profiled bars
Automated welding process for high-precision manufacturing
Perfectly adjusted screen basket profiles
Available for all screens
Surface finishing as required
Wire Wrapped Screen Application
1, Deep well pump
2, Dive the water pump.
3, In the water-treating equipment,
4, The environmental protection
5, The sea water transforms into the industrial water and life use water desalination treatment
6. Running water treatment
7, Water softening treatment
8, The petroleum industry
9, The petroleum product terminal filters and the chemical acid
10, The alkali liquid filters
11, The ethyl alcohol and so on the organic solution recycling filters.
Wire Wrapped Screen Parameter selection table
SIZE
(inch) | O.D
(mm) | SLOT
(mm) | LENGTH
(m) | Collapse Strength
(BAR) | Tensile Weight
(ton) | Wire size (WxH) (mm) | RODS (mm) |
| 3-1/2 | 88.9 | 1.0 | 3 | >22 | 10.2 | 2.3*3.5 | 3.8mm/22 |
| 4-1/2 | 114.3 | 1.0 | 3 | >28 | 11.5 | 2.3*3.5 | 3.8mm/22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | >40 | 12.8 | 2.3*3.5 | 3.8mm/32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | >33 | 12.8 | 2.3*3.5 | 3.8mm/32 |
| 6-5/8 | 168.3 | 0.63 | 5.8 | >83 | 45 | 3.2*6.0 | 6.0mm/32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >34 | 21.9 | 2.3*3.5 | 3.8mm/48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >50 | 38.2 | 3.0*5.0 | 4.0mm/48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >60 | 46 | 3.2*6.0 | 5.0mm/48 |
| 10-3/4 | 273.1 | 0.75 | 5.8 | >50 | 32.9 | 2.3*3.5 | 4.9mm/55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | >60 | 39.5 | 3.0*5.0 | 4.9mm/55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | >100 | 48 | 3.2*6.0 | 5.0mm/55 |
| 12-3/4 | 323.9 | 1.0 | 5.8 | >120 | 37.2 | 3.0*5.0 | 4.0mm/50 |
| 14 | 355.6 | 1.0 | 3 | >80 | 37.8 | 3.0*5.0 | 4.0mm/59 |
